Flexcon’s top of the line Pro Lite Series composite well tanks.

The ProLite SS goes one step futher by adding a stainless steel elbow and increasing the maximum working pressure to 150 PSI. Combined with Flexcon’s silver-ion-infused, anti-marobial CAD-2 diaphragm design inside, they are now better than ever! When you need the ultimate well tank, go with proven Flexcon performance. The ProLite SS, it just doesn’t get any better than this!

Specifications

Model CSS35
Diameter 16.5 (inches) / 41.9 (cm)
Height 48.9 (inches) / 124.2 (cm)
System Connection 1" NPT (Stainless Steel Elbow, this tank utilizes a long tank tee)
Volume 35 (gallons) / 132.5 Litres
Weight (empty) 33.5 lbs / 15.2 kg
Drawdown 20/40 psi = 14.1 usg/52.3 lt, 30/50 psi = 11.9 usg/44.2 lt, 40/60 psi = 10.3 usg/38.3 lt

Warranty: 5 year limited


Materials of Construction
Top and bottom domes: Injection molded copolymer polypropylene
Shell: Extruded copolymer polypropylene
Outer shell: Fiberglass-wound, coated with epoxy resin
Water chambers: Top diaphragm is 100% butyl rubber, lower water
chamber is anti-microbial, copolymer polypropylene
Base: Copolymer polypropylene
Connection: Stainless steel
Air valve: Easy to access brass valve with o-ring seal
Testing: High pressure, seam weld, helium, final precharge check

Downloads for the Pro Lite Series

Brochure

Specification Sheet

Installation & Maintenace
