Franklin Electric, FPS 3200 Series 4", SS, 10gpm 0.5 hp 230v, 2-Wire, 1Phase

Call For Price
1-866-489-4004

Call For Price 1-866-489-4004
SKU	10FRD05S4-2W230
Brand	Franklin Electric
Availability	By Phone & E-Mail 1-866-489-4004
	4 Related Products

In Stock:	Ships in 1 - 3 days
Shipping:	Calculated at checkout

Overview
Brand Brand Info
Related Related Products 4

Franklin FPS 3200 Series 4" Stainless Steel Submersible Pumps

10gpm, 1/2 hp, 230volt, 2-Wire, Single Phase, Stainless Steel, Submersible Pump

The FPS 3200 series submersible pump features a higher output and performance than other pumps in its class. The reduced pump diameter makes it a true 4" pump, ideal for wells with liners or 4" casings. When you buy from The Water Guy an authorized Franklin Pump Key Dealer you will receive a 5-year full warranty.

Features

Solid Stainless Steel Pump End

Pump diameter is smaller than standard 4" submersible pumps for easier installation in reduced diameters, wells with liners and 4" wells
Hex rubber bearing and ceramic shaft sleeve allows sand and abrasives to pass through, virtually eliminating shaft wear and upper bearing failures
Improved hydraulic performance for deeper set depths at all horsepower and flow ratings
Floating stage design allows for maximum efficiency while minimizing the downthrust load that is transferred to the motor
Advanced thermoplastic diffuser and disc with 300 Series stainless steel thrust and eye seal protection for durability and abrasion resistance
Scalloped impellers provide high performance to increase pressure output while reducing system losses from friction
Removable and replaceable spring-loaded check valve

Stainless steel pump intake screen and stainless steel cable guard
Maximum water temperature: 120 °F/49 °C
Powered by a corrosion-resistant Franklin Electric submersible 4" motor with lightening protection built-in

This link has the complete 3200 Series line including pumping charts and pump curves, click here.

Complete Franklin Pump Number (motor & pump end) - 96311010

Model Number - 10FRD05S4-2W230

Made in North America by Franklin Electric

*the schaeffer 3200 series and the FPS 3200 Series are the same pump line, Franklin continues to consolidate thier many names.

* This pump requires a control box or drive to operate it, see the related tabs to find out more

Product Category Filters Product Lines Filtered by Category Franklin Electric Product Category Filters

Franklin Electric has long been recognized as the world's largest manufacturer of submersible electronic motors, controls and pumps. Franklin products are widely used in residential, commercial, agricultural and industrial water pumping applications.

Franklin's product lines include the constant pressure systems MonoDrive and SubDrive Series, submersible pumps, magnetic drive pumps, jet pump systems, water garden pumps and a wide variety of utility pumps.

[+] [–] More About Franklin Electric

Founded in 1944, Franklin Electric has grown from a small motor manufacturing company into a worldwide recognized provider of complete water systems.

The Water Guy, fully established in 1989 is an actual service company that includes its own warehouse and retail store. (Yes, when your order with us you are ordering direct).

Our warehouse carries many items that are not yet on our website. If you are looking for a Franklin Electric control box, well pump, submersible or related part or accessory that is not found on this page, then please contact us by email or call our office (1-866-489-4004) to speak to an experienced "in the field" water technician that can assist you with your specialty order and unique concerns.

NOTE: Franklin Electric products are standard stock items for us.

Get Franklin Electric Constant Pressure Systems like the MonoDrive series, standard control boxes, motors, well pumps submersible or jet and their parts direct to your door. Our water technicians can assist you all the way through the process.
