Pentair 3G Slim Line Filter Housing – 3/8" JG Quick Connect, White, Integral Bracket with PR Valve

Pentair 3G Slim Line Filter Housing – 3/8" JG, White on White, Quick-Change Integral Bracket with PR Valve

Description: The Pentair 3G Slim Line Filter Housing is designed for low-flow filtration applications, offering a slim profile and high chemical compatibility. This model features a 3/8" White/White quick-change integral bracket with a pressure relief button for easy cartridge changes and leak-proof operation.

Key Features:

• Slim design for space-saving installation
• High chemical compatibility for challenging applications
• Quick-change integral bracket for fast and secure mounting
• Pressure relief button for safe cartridge replacement
• Accepts DOE (double open end) cartridges
• Leak-proof seal

Specifications:

• Connection Size: 3/8" Quick Connect Push Fittings
• Cap/Sump Color: White/White
• Mount Style: Quick-Change Integral Bracket with Pressure Relief Valve
• Maximum Dimensions: 13.75" x 5.38" (349 mm x 137 mm)
• Initial Pressure Drop: 2 psi @ 5 gpm (0.14 bar @ 19 Lpm)
• Housing Material: Polypropylene (opaque)
• Cap Material: Reinforced polypropylene
• O-Ring: #237 EPDM
• Temperature Rating: 40–125°F (4.4–51.7°C)
• Maximum Pressure: 125 psi (8.6 bar)

Benefits:

• Built-in bracket for easy installation
• Clear or opaque sump options for visual inspection or enhanced chemical resistance
• Buttress threads for strength and easier cartridge changes
• With John Guest Built-In Connections

Applications:

• Residential and commercial water filtration
• Low-flow filtration systems
• Chemical filtration setups

Accessories (sold separately, see our related parts tab):

• SW-1A Wrench for Slim Line
• O-rings

Manufacturer:

Pentair Residential Filtration, LLC

Spec Sheet:

Click Here for the Pretair/Pentek Spec sheet on this housing
